Prima Mu Microscope

Prima Mu Microscope
Prima Mu Microscope
Send Inquiry
Product Code : Prima Mu
Product Description

A Quality Solution for Value-driven Diagnostics

The Prima Mµ is intended for routine inspection and in screening clinical environments. A well-designed apochromatic optical system with a high output LED built directly into the microscope housing provides users with a compact solution. The arm system has been carefully designed to mitigate vibration and lower the system's center of gravity to provide a more stable, lighter weight solution.

Prima Mu Specifications

Binocular Tubes45° inclined (standard), 0-210° inclinable, straight head (optional)
EyepiecesWF 10X/18 mm with eye guards, lockable diopter adjustment ± 5 mm Optional: WF 12.5X/18 mm
Apochromatic Magnichanger0.6X, 1.0X, 1.6X
Objectivef-250 mm with fine focus (standard); Options: NuVarwith focal length adjustment f-300-400 mm; f-300 mm or f-400 mm with fine focus; f-200 mm fixed objective; objective lens protector
Light Source27W LED / 75K lux
Built-in FiltersGreen / Yellow
Vertical Movement of Arm500 mm with power saver light cut-off at park position
Microscope Carrier Movement± 155°
Mounting OptionsFloor stand, wall mount and ceiling mount


Accessories (Optional)

  • Beam splitter straight/inclined
  • Rotoplate and/or Extender
  • Camera adapters for Canon/Nikon/Sony systems
  • iVu S5 5MP integrated digital camera module with on-device capture button and SD card; USB v2.0 and HDMI ports
  • Motorized Z-axis with foot pedal
